Windows are essential in protecting and insulating your home, providing insulation and security, and providing aesthetic design options to increase energy efficiency. Select the best vacuum double glazing.

Window glass comes in many varieties – insulation, Low-E coatings, laminated or tempered options are among them – each performing differently and contributing a unique appearance to any given window replacement project. Understanding which types are available is crucial.

Tempered Glass

Tempered glass (toughened glass) is made through controlled thermal or chemical treatments to increase its strength. It is an excellent option for kitchen splashbacks, bathroom wall partitions, and frameless doors in the home. Tempered glass also makes an excellent option for exterior windows or doors that must provide better protection from harsh elements while potentially experiencing stress from impact or heavy banging.

Tempered glass is heated just below its melting point before rapidly cooling, altering its crystalline structure. This compresses outer surfaces while leaving the core in tension, giving this material its impressive strength. Once formed, tempered glass can be cut into various shapes and sizes, and additional beauty may be achieved through beveling, polishing, or V-grooving techniques.

Due to this design, tempered glass is up to four times stronger than heat-strengthened glass and breaks into small, granular chunks rather than jagged shards upon impact, making it safer and significantly reducing injury risks.

As with all forms of glass, tempered glass can still be damaged during transport and installation processes. While nicking or chipping may not immediately lead to breakage, stress concentrations that result in larger cracks or shattering could eventually develop over time and eventually result in more giant shards of broken material.

Though damage of this nature is easily repairable, detecting it may prove more challenging. Various methods are available for spotting cracked or shattered glass, including its color and texture or the presence of a figure eight pattern where broken pieces connect.

Window film can also significantly increase window protection. Applied over existing windows, this security film utilizes ultra-thin plastics and adhesives that, upon being struck by criminal attempts at forced entry or flying debris from explosions, hold fragments together into thumbnail-sized fragments to reduce injuries while discouraging criminals from breaking in by smashing glass surfaces. This significantly lowers injury risks while discouraging criminals from trying to gain entry by smashing it.

Low-E Glass

Low-E (low emissivity) glass windows are designed to reduce energy loss by improving their ability to reflect heat back into the room. This is achieved by applying an extremely thin layer of metallic particles onto the glass pane surface—this acts as a sieve, filtering out long wavelengths while permitting short ones through. By altering particle composition or adding or subtracting layers, various Low-E glasses can be fabricated according to individual projects and climate needs.

Low-E glass’s primary benefit lies in its ability to reflect and trap heat, keeping your home comfortable during both temperate and extreme weather conditions. To understand this process, envision the silver lining inside a thermos; heat bounces off this layer and keeps things toasty, reducing energy bills by keeping warm air inside your home rather than being lost through windows.

Low-E glass has an important feature that separates it from its competitors: its ability to block UV radiation. UV rays come from all sources, including sunlight; however, quality Low-E glazing can block almost 100% of these invisible rays from entering your home.

Instead of relying on metal frames and sashes for heating or cooling, multi-pane Low-E glass windows use inert Argon gas to fill between panes of glass—an inert gas with greater resistance to heat flow than air, which increases energy efficiency even further.

An energy-efficient multi-pane Low-E glazing can not only lower energy bills but also help increase natural light penetration into your home for an enlightened living experience. By selecting double-glazed windows that meet your specific needs and budget requirements, you can make sure you receive only top-quality glass at reasonable costs. When making this selection, be sure to speak with an expert who can guide you toward finding glazing suitable for both you and your project requirements. For more information about double-glazed windows, visit your local Pella Showroom and schedule a free consultation session today!

Laminated Glass

Laminated glass windows are an innovative form of safety window construction featuring plastic layers on both sides for increased impact resistance. They are 8 times more potent than clear windows and protect people and furnishings inside a home or commercial building. Laminated windows are easy to keep clean, as their interlayers block UV rays, decreasing the risk of skin cancer and other health concerns.

Laminated windows are a popular choice for safety and security applications due to their ability to withstand an impact without shattering or falling off their frames, and they are more resistant to fire and earthquakes than other materials.

Laminated windows have an array of qualities that make them ideal for deterring burglars from breaking into stores and businesses. They can stall criminals long enough for store owners to contact the police, helping prevent costly inventory losses while helping retailers retain customers. In addition, laminated windows make great displays for merchandise and can attract potential customers to stores.

Laminated windows are an excellent choice for homes with young children as the PVB layers help prevent the glass from shattering into sharp pieces that could hurt people. Furthermore, laminated windows can increase sound transmission class (STC) ratings of buildings by combining different glass thicknesses and using special interlayers known as acoustic membranes such as Trosifol.

Laminated glass windows can also provide offices and other commercial buildings looking to reduce noise levels, which is a great way to do so. When coupled with high-performance coatings that enhance thermal insulation and solar control, laminated glazing windows can also add aesthetic finishes for aesthetic finish purposes. Laminated glazing is commonly found in curtain walls, skylights, glass facades, railings/balustrades and is tinted or etched for visual enhancement purposes.

Safety Glass

Building codes stipulate that safety glass be used in areas where impact hazards could arise. For residential homes, this includes areas within two feet of doors or windows larger than nine square feet, while in commercial settings, it could include skylights, stair balustrades, and access panels used to connect fire safety or defibrillation equipment. Safety glazing helps reduce injuries caused by sharp splinters while increasing security by making it harder for burglars to break in.

Safety glazing comes in two varieties—laminated and tempered. The latter is typically subjected to an impact test that involves a pendulum at various force levels. This simulates what would occur if someone ran at speed into the window while impact testing to see how well the glass held together under pressure.

Laminated glass is created by joining multiple panes of glass together with a plastic interlayer, commonly known as an adhesive plastic interlayer, such as PET plastic or acrylic resin. When broken, PVB resin holds fragments together to reduce injury. Furthermore, laminated glazing offers much higher damage resistance, thus decreasing maintenance and repair costs for homeowners and businesses alike.

Tempered and laminated glass offers designers endless creative options when it comes to glazing solutions. Both types of safety glass offer energy efficiency benefits such as UV protection and low-e coatings; furthermore, they are resistant to scratches and marks, so they will last longer, further cutting maintenance costs in the long run.

Harold McMaster of Ohio wasn’t the inventor of tempered glass, but he was the first person in America to commercialize it commercially. He patented a process for heating and cooling glass to produce its unique properties called “safety tempering,” which enhanced strength while maintaining shape retention—ideal for shower doors and interior applications such as bathroom vanity tops. Tempered glass also stands up well under high temperatures and other environmental conditions and is readily combinable with wood or metal surfaces.
